Cat 3 GD: Ex nA II T4: IP66 Stainless Steel Housed Terminal box ATEX Cat 3 compatiable for hazardous areas. CNOMO interface available in various materials.
Datasheet
- Non-incendive coil suitable for Zone 2 areas only, manufactured in accordance with the requirements of EN/IEC60079-15 and EN/ IEC60079-31.
- Such that under normal operation it is not capable of igniting a surrounding explosive atmosphere and a fault capable of causing ignition is not likely to occur.
- Covered by BASEEFA approval, Certificate Number BAS03ATEX0296X category ExnA T4 and T6.
FEATURES
- M20 x 1.5 conduit entry or 1/2 NPT
- Protection class IP66 according to ENBS60529
- Connection by 2-pole 2.5mm2 terminal strip + earth
- Continuously rated
- Maximum permitted voltage variation ±10%
- Maximum ambient temperature +60¡c
- Low power consumption
- Wide range of voltages available
MATERIAL SPECIFICATIONS
| STANDARD | |
| Coil Case | ANC1B Stainless Steel Epoxy Powder Coated |
| Armature and Fixed Pole Piece | Magnetic Solenoid Quality Stainless Steel |
| Springs | Stainless Steel |
| Seals and Seats | Viton |
| Coil Former | 30% Glass Filled PBT |
| Magnetic Wire | Class H Coated Copper |
SOLENOID SPECIFICATIONS
| DC Solenoid Coil | AC Solenoid | |
| Voltage Standard | 24 | 24, 110, 220, 240 (50/60 Hz) |
| Voltage Tolerance | ±10% | ±10% |
| Ambient Temperature | -40 to +60°C | -40 to +60°C |
| Duty Cycle | 100% | 100% |
| Degree of Protection | IP66 | IP66 |
| Electrical Connection | Junction Box with M20 Conduit Entry | Junction Box with M20 Conduit Entry |
| Power Consumption | 2.4W or 1.3W | Pull in – 10VA, Holding – 5VA |
| Pressure Range | 0 – 10 bar | 0 – 10 bar |
+
Cat 3 GD: Ex nA II T4: IP66 Stainless Steel Housed Terminal box
