Safe Area IP66 Stainless Steel Terminal box Safe area use. CNOMO interface available in various materials.

  • Safe area Stainless Steel coil with Terminal box connection and screwed terminals.


  • M20 x 1.5 conduit entry or 1/2 NPT
  • Protection class IP66 according to ENBS60529
  • Connection by 2-pole 2.5mm2 terminal strip + earth
  • Continuously rated
  • Maximum permitted voltage variation ±10%
  • Maximum ambient temperature +80°C
  • Low power consumption
  • Wide range of voltages available



Coil CaseANC1B Stainless Steel Epoxy Powder Coated
Armature and Fixed Pole PieceMagnetic Solenoid Quality Stainless Steel
SpringsStainless Steel
Seals and SeatsViton
Coil Former30% Glass Filled PBR
Magnetic WireClass H Coated Copper



Coil TypeDC Solenoid CoilAC Solenoid
Voltage Standard2424, 110, 240 (50/60 Hz)
Voltage Tolerance±10%±10%
Ambient Temperature-20 to +80°C-20 to +80°C
Duty Cycle100%100%
Degree of ProtectionIP66IP66
Electrical ProtectionJunction Box with M20 Conduit EntryJunction Box with M20 Conduit Entry
Power Consumption2.4W or 1.3WPull in – 9VA, Holding – 5VA
Pressure Range0 – 10 bar0 – 10 bar
